WA1893 tungsten alloy rod has a series of excellent properties. Its ingredient is 92.5% tungsten、7.5% nickel and copper. It is used in collimator and shielding components to provide protection against X-ray and γ-ray radiation.
Chinatungsten Online offers a growing range of tungsten alloy rod that can be cut to size to customer specified thickness, length, surface finish. We also offer precision machining rod, threaded rod and gun-drilled rod.
The properties of WA1893 tungsten alloy rod are:
WA1893 tungsten alloy rod
Matrix: 92.5% W
Binder: 7.5% Ni-Cu
Density: 17.5g/cm3 and 0.64lb/in3
Hardness Rockwell: 19C
Ultimate Tensile Strength: 110, 000psi
Yield Strength (0.2% offset): 88,000psi
Elongation: 10% in 1"
Modulus of Elasticity：42x106PSI
Proportional Elastic Limit: 45,000PSI
Coefficient of Thermal Expansion: 4.9 X 10-6/°C (20~400°C)
Thermal Conductivity: 0.27CGS Units
Electrical Conductivity: 15% IACS
Magnetic Properties: Non-magnetic
ASTM B777-07: Class 2
More details, please visit:
http://www.tungsten-alloy.com/tungsten-alloy-rod.html
