HD17.7 tungsten alloy rod is manufactured using Chinatungsten Online’ strict quality measures, guaranteeing a consistent, reliable material. Its ingredient is 93% tungsten and the same content of nickel、iron and molybdenum. It has a wide array of industries for use in diverse applications, including highly advanced medical diagnostic equipment and aerospace field.
The Properties of HD HD17.7 tungsten alloy rod are:
Density: 17 .7 Gms/cc and 0.639 Lbs/ in3
Hardness Rockwell: 30 C
Ultimate Tensile Strength: 130,000 PSI
Yield Strength(2% offset): 90,000 PSI
Elongation: 10 % in 1"
Proportional Elastic Limit: 60,000PSI
Modules of Elasticity: 53 x 106 PSI
Coefficient of Thermal Expansion: 4.5 X 10-6/°C (20~400°C)
Thermal Conductivity: 0.27 CGS Units
Electrical Conductivity: 14 % IACS
Magnetic Properties: Slightly Magnetic
